- 4 Mono Mic | Line Channels XLR, ¼”Jack – Balanced
- Mic Input Impedance | 2kΩ
- Line Input Impedance | 47kΩ
- Low Cut Switch
- Gain Potetiometer
- Compressor Potentiometer
- Individual Low, Mid and Hi EQ Potetiometers | -15/+ 15dB
- Effects Send Potentiometer
- Aux Potetiometer
- Pan Potetiometer
- Level Potetiometer
- 2 Stereo Line Channels | Unbalanced, ¼”Jack, Left and Right
- Input Impedance |10kΩ
- -10dB Attenuation Switch
- Individual Low, Mid and Hi EQ Potetiometers | -15/+ 15dB
- Aux Potentiometer
- Balance Potetiometer
- Level Potetiometer
- 16 DSP Effects Processor
- Effect Repeat Potetiometer
- Effect Level Potetiometer
- Aux Send and Return Potetiometer
- 2TK Play | MP3-USB Level Potetiometer, Switchable
- MP3-USB Media Player | Recorder with LCD Screen | Play, Pause, Record, Folder select
- Headphones | Control Room Potetiometer
- 48V Phantom Power Switch
- Master Level Fader | 60mm
- 8 Bar LED Master Level Indicators
- Unbalanced ¼”Jack Outputs Left and Right | 75Ω
- Unbalanced ¼”Jack Control Room Outputs Left and Right | 75Ω
- RCA Record Output Left and Right | 75Ω
- Stereo Unbalanced Aux Return ¼”Jack Left and Right | 10kΩ
- Aux Send ¼”Jack | 75Ω
- 2TK Play | Unbalanced RCA Left and Right | 10kΩ
- Seperate PSU Adaptor
- Dimensions | 275mm (w) 275mm (d) 60mm (h)
